Expert 24 LX User Manual
Installation
2-3
Step 3
Place the stand beam upright on the T-stand and put the screws into the holes but do not
tighten them at this step.
Step 4
Position both the left Support and right Support perpendicularly to the T-stand and put the
screws into the holes and tighten them as shown in Figure 2-3.
T-stand
Stand Beam
Figure 2-2
Figure 2-3
Support for left side
Support for right side
