Expert 24 LX User Manual
Illustrator Plug-In A-5
Segmental Positioning
For precise cutting quality, it is suggested to select
“Segmental Positioning” when you are working on an
extra long or large-sized image to increase cutting
accuracy.
Segmental Positioning
X Step: The distance of intermediate position on the
X axis
Y Step: The distance of intermediate position on the
Y axis
Range: 200mm~600mm
Optimized Setting: Less than 500mm
The system will create the marks as shown in the picture below
Segmental Positioning
