Expert 24 LX User Manual
GreatCut Instruction A-4
Note:
1. To save your materials, in addition to amending object margins, you can also adjust the length of
the registration marks (5mm minimum) when you apply the above function(see table 1 for
suggestions based on different material sizes). The smaller the size is, the smaller the distance
between the object and the registration marks is (see the figures below).
Table 1
*25mm is the suggested value for the registration mark length
2. The size of the registration marks would affect the accuracy of registration mark detection so
please make sure the amount you enter is reasonable.
Page size
(unit: mm)
Suggested mark length
(unit: mm)
A6 (105 x 148) 5
A5 (148 × 210) 8
A4 (210 × 297) 11
A3 (297 × 420) 16
A2 (420 × 594) 23
A1 (594 × 841) and above 25*
Area to be cut
