12.2 General Technical Data
Line power supply (L1, L2, L3)
Supply voltage 380–480 V ±10%
Supply voltage 525–600 V ±10%
AC line voltage low / line drop-out:
During low AC line voltage or a line drop-out, the drive continues until the intermediate circuit voltage drops below the
minimum stop level, which corresponds typically to 15% below the drive's lowest rated supply voltage. Power-up and full torque
cannot be expected at AC line voltage lower than 10% below the drive's lowest rated supply voltage.
Supply frequency 50/60 Hz ±5%
Max. temporary imbalance between line phases 3.0% of rated supply voltage
True Power Factor (λ) ≥ 0.9 nominal at rated load
Displacement Power Factor (cosφ) near unity (> 0.98)
Switching on input supply L1, L2, L3 (power-ups) maximum once/2 min.
Environment according to EN60664-1 overvoltage category III/pollution degree 2
The unit is suitable for use on a circuit capable of delivering not more than 100 k RMS symmetrical Amperes, 480/600 V
maximum.
Motor output (U, V, W)
Output voltage 0–100% of supply voltage
Output frequency 0–800* Hz
Switching on output Unlimited
Accel/Decel Times 1–3,600 s
* Voltage and power dependent
Torque characteristics
Starting torque (Constant torque) maximum 110% for 1 min.
*
Starting torque maximum 135% up to 0.5 s
*
Overload torque (Constant torque) maximum 110% for 1 min.
*
*Percentage relates to AF-600 FP Drive's nominal torque.
Cable lengths and cross-sections for control cables
Max. motor cable length, shielded 500 ft [150 m]
Max. motor cable length, non-shielded 1000 ft [300 m]
Maximum cross-section to control terminals, flexible/ rigid wire without cable end sleeves 1.5mm
2
/16 AWG
Maximum cross-section to control terminals, flexible wire with cable end sleeves 1mm
2
/18 AWG
Maximum cross-section to control terminals, flexible wire with cable end sleeves with collar 0.5mm
2
/20 AWG
Minimum cross-section to control terminals 0.25mm
2
/ 24AWG
Digital inputs
Programmable digital inputs 4 (6)
Terminal number 18, 19, 27
1)
, 29, 32, 33,
Logic PNP or NPN
Voltage level 0–24 V DC
Voltage level, logic'0' PNP <5 V DC
Voltage level, logic'1' PNP >10 V DC
Voltage level, logic '0' NPN >19 V DC
Voltage level, logic '1' NPN <14 V DC
Maximum voltage on input 28 V DC
Input resistance, R
i
approx. 4 kΩ
All digital inputs are galvanically isolated from the supply voltage (PELV) and other high-voltage terminals.
1) Terminals 27 and 29 can also be programmed as output.
Specifications AF-600 FP Design and Installation Guide
