Control card, 10 V DC output
Terminal number 50
Output voltage 10.5 V ±0.5 V
Max. load 25 mA
The 10 V DC supply is galvanically isolated from the supply voltage (PELV) and other high-voltage terminals.
Control characteristics
Resolution of output frequency at 0–1000 Hz ±0.003 Hz
System response time (terminals 18, 19, 27, 29, 32, 33) ≤ 2 ms
Speed control range (open-loop) 1:100 of synchronous speed
Speed accuracy (open-loop) 30-4,000 rpm: Maximum error of ±8 rpm
All control characteristics are based on a 4-pole asynchronous motor
Surroundings
Enclosure, frame size 4X and 5X IP00, IP21, IP54
Enclosure, frame size 6X IP21, IP54
Vibration test 0.7 g
Relative humidity 5%–95% (IEC 721-3-3; Class 3K3 (non-condensing) during operation
Aggressive environment (IEC 60068-2-43) H
2
S test
class kD
Test method according to IEC 60068-2-43 H2S (10 days)
- with derating max. 131° F [55°C]
1)
- with full output power, typical EFF2 motors max. 122° F [50°C]
1)
- at full continuous drive output current max. 113° F [45°C]
1)
1)
For more information on derating see the AF-600 FP, section on Special Conditions.
Minimum ambient temperature during full-scale operation 32° F [0°C]
Minimum ambient temperature at reduced performance 14° F [-10°C]
Temperature during storage/transport -13°–149°/158° F [-25°–+65°/70°C]
Maximum altitude above sea level without derating 3,300 ft [1,000 m]
Maximum altitude above sea level with derating 10,000 ft [3,000 m]
Derating for high altitude, see section on special conditions in the Design Guide
EMC standards, Emission EN 61800-3, EN 61000-6-3/4, EN 55011, IEC 61800-3
EMC standards, Immunity
EN 61800-3, EN 61000-6-1/2,
EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6
See section on special conditions in the Design Guide!
Control card performance
Scan interval 5 ms
Control card, USB serial communication
USB standard 1.1 (Full speed)
USB plug USB type B “device” plug
CAUTION
Connection to PC is carried out via a standard host/device USB cable.
The USB connection is galvanically isolated from the supply voltage (PELV) and other high-voltage terminals.
The USB connection is
not galvanically isolated from ground protection. Use only isolated laptop/PC as connection to the
USB connector on the adjustable frequency drive or an isolated USB cable/drive.
Specifications AF-600 FP Design and Installation Guide
DET-768A 12-15
