Operation Status
Ramping The motor is accelerating/decelerating using
the active ramp-up/down. The reference, a
limit value or a standstill is not yet reached.
Ref. high The sum of all active references is above the
reference limit set in H-75 Warning Reference
High.
Ref. low The sum of all active references is below the
reference limit set in H-74 Warning Reference
Low.
Run on ref. The adjustable frequency drive is running in
the reference range. The feedback value
matches the setpoint value.
Run request A start command has been given, but the
motor is stopped until a run permissive signal
is received via digital input.
Running The adjustable frequency drive runs the
motor.
Sleep Mode The energy saving function is enabled. The
motor has stopped, but will restart automat-
ically when required.
Speed high Motor speed is above the value set in
H-73 Warning Speed High.
Speed low Motor speed is below the value set in
H-72 Warning Speed Low.
Standby In Auto On Auto mode, the adjustable
frequency drive starts the motor with a start
signal from a digital input or serial communi-
cation.
Start delay In F-24 Holding Time, a delay starting time was
set. A start command is activated and the
motor will start after the start delay time
expires.
Start fwd/rev Start forward and start reverse were selected
as functions for two different digital inputs.
The motor starts in forward or reverse
depending on which corresponding terminal is
activated.
Stop The adjustable frequency drive has received a
stop command from the keypad, digital input
or serial communication.
Trip An alarm occurred and the motor is stopped.
Once the cause of the alarm is cleared, the
adjustable frequency drive can be reset
manually by pressing [Reset] or remotely by
control terminals or serial communication.
Operation Status
Trip lock An alarm occurred and the motor is stopped.
Once the cause of the alarm is cleared, power
must be cycled to the adjustable frequency
drive. The adjustable frequency drive can then
be reset manually by pressing [Reset] or
remotely by control terminals or serial
communication.
Table 8.3
Status Messages AF-600 FP Design and Installation Guide
DET-768A 8-3
