No. Description Warning Alarm/Trip Alarm/Trip Lock Parameter Reference
31 Motor phase V missing (X) (X) (X) H-78 Missing Motor Phase
Function
32 Motor phase W missing (X) (X) (X) H-78 Missing Motor Phase
Function
33 Inrush fault X X
34 Fieldbus communication fault X X
35 Option Fault X X
36 Mains failure X X
38 Internal fault X X
39 Heatsink sensor X X
40 Overload of Digital Output Terminal 27 (X) E-00 Digital I/O Mode,
E-51 Terminal 27 Mode
41 Overload of Digital Output Terminal 29 (X) E-00 Digital I/O Mode,
E-52 Terminal 29 Mode
42 Overload of Digital Output On X30/6 (X) E-56 Term X30/6 Digi Out
(OPCGPIO)
42 Overload of Digital Output On X30/7 (X) E-57 Term X30/7 Digi Out
(OPCGPIO)
45 45 Earth Fault 2
46 Pwr. card supply X X
47 24 V supply low X X X
48 1.8 V supply low X X
49 Speed limit X (X) H-36 Trip Speed Low [RPM]
50 Auto tune calibration failed X
51 Auto tune check U
nom
and I
nom
X
52 Auto tune low I
nom
X
53 Auto tune motor too big X
54 Auto tune motor too small X
55 Auto tune Parameter out of range X
56 Auto tune interrupted by user X
57 Auto tune timeout X
58 Auto tune internal fault X X
59 Current limit X
60 External Interlock X
62 Output Frequency at Maximum Limit X
64 Voltage Limit X
65 Control Board Overtemperature X X X
66 Heatsink Temperature Low X
67 Option Configuration has Changed X
69 Pwr. Card Temp X X
70 Illegal Drive configuration X
76 Power Unit Setup X
79 Illegal PS config X X
80 Drive Initialized to Default Value X
91 Analog input 54 wrong settings X
92 No-Flow X X AP-2#
93 Dry Pump X X AP-2#
94 End of Curve X X AP-5#
95 Broken Belt X X AP-6#
96 Start Delayed X AP-7#
97 Stop Delayed X AP-7#
