3.3 Pumps
Introduction
This section describes the two high precision system pumps, A and B, that pump buffers
and samples through the flow path.
Illustration
The illustration below shows the front of pump A.
5 6
7
8
2 3 41
DescriptionPart
Rinsing solution inlet, from the rinsing solution bottle1
Inlet, from Inlet Valve module2
Rinsing solution inlet, from left pump head3
Inlet, from Inlet Valve module4
Rinsing solution outlet, to right pump head5
Outlet, to the flow restrictor6
