3.7 In-line filter (optional)
Introduction
This section describes the optional in-line filters. The filters are used to prevent particles
in solutions from reaching the column. For installation and replacement of a filter, see
the ÄKTA pilot 600 Operating Instructions.
Illustration
The illustrations below show the two in-line filter options, a stainless steel housing and
an ULTA™ Capsule CG filter from GE.
1
2
3
DescriptionPart
Inlet, stainless steel housing1
Air vent valve, stainless steel housing2
Outlet, stainless steel housing3
