GE BrightSpeed Elite - Patient Table (H-Power)

GE HEALTHCARE 
D
IRECTION 5141177-100, REVISION 14 BRIGHTSPEED ELITE, EDGE, EXCEL: PRE-INSTALLATION
Page 108 Section 2.0 - Mounting Data, Including Seismic
Figure 6-4 Patient Table (H-Power)
CT3511A
16.00
(406.4)
CRADLE
EXTEN
SION
198.96
(5053.6)
91.90
(2334.3)
Z
N OTE :
D I M E N SIO N S AR EI N
I NCH ES ( M ILLI M ETE R S )
C E N TE R OF G RA VITY
C E N TE R OF G RA VITY IS
WIT
H 450 L B ( 205 K G )
P A TIE N TF U LLY EXTE ND E D
This location leveling only
31.55
(801.4)
96.21
(2443.7)
12.13
(308.1)
Z
These two locations, leveling only No Anchors
