GE HEALTHCARE 
D
IRECTION 5141177-100, REVISION 14 BRIGHTSPEED ELITE, EDGE, EXCEL: PRE-INSTALLATION
Page 150 Section 4.0 - Contractor Supplied Components
Section 4.0
Contractor Supplied Components
Section 5.0
Fuse
REFERENCE ASSOCIATED
EQUIPMENT
MATERIAL/LABOR SUPPLIED BY
CUSTOMER CONTRACTOR
USA VENDOR / CAT NO. GE
CATALOG
A1
380 - 480V
50/60 Hz
Fusible Disconnect
and Magnetic
Contactor
3 Pole, 380V - 480V, Combination breaker
with magnetic contactor. Includes control
transformer, optional UPS interface, On/Off
controls and auto-restart feature
Recommended:*
• E4502AC (110A)
• E4502AB (90A)
ITL In-suite Telephone
Lines
Supply 2 voice-grade telephone lines. One
line must be a direct number from outside the
facility – do not route this line through a
telephone switchboard. Telephone line
operating charges are paid by customer.
BBNC
(required)
Broad-Band
Network
Connection
Broad-Band network connection wall jack,
located within 1m (39inches) of console
location, for internal hospital networking and
InSite Broad-Band connectivity.
System
Components
Reference the system installation drawings
supplied by Installation Support Services
within your geographic area.
*Refer to Table 9-16 on page 152.
Table 9-13 Contractor-Supplied Components
ITEM NUMBER QTY FRU CODE DESCRIPTION/NAME
1 2351493 1.0 Yes 100A FUSE
2 2364059 1.0 Yes GLASS FUSE
3 46-170021P50 1.0 Yes FUSE 12 AMPS 250 VOLTS BUSSMAN MDA12 DUAL ELEMENT.
4 46-170021P15 1.0 Yes Time Lag FUSE 8 AMPS 250 VOLTS (REVIEWED TK, 7/91).
5 2336517-2 1.0 Yes FUSE 25 AMPS 700 VOLTS 2.5M SECONDS
6 46-170021P52 5.0 Yes FUSE 3 AMPS 250 VOLTS (REVIEWED TK, 7/91).
7 46-170021P10 2.0 Yes 006.000A 0250V 3AG FAST UL/C (REVIEWED TK, 7/91).
8 46-170021P101 1.0 Yes FUSE 20 AMPS 700 VOLTS 2~ LONG X 9/16~ DIA FAST BLOW
9 46-170021P106 1.0 Yes FUSE 8 AMPS 250 VOLTS BUSSMANN ONLY
10 46-170021P31 2.0 Yes 1/2A, 250V SLO-BLO FUSE. TYPE 3AG, 1.25~ X 0.25~ GLASS BODY. (REVIEWED TK, 7/
91).
11 2106993-5 2.0 Yes FUSE 20 AMPS 500 VOLTS .3 SECONDS
12 46-327160P1 1.0 Yes 12.0A, 125VAC, DUAL ELEMENT TIME DLY FNM-12, 0.406 X 1.5 LG, FIBER BODY
13 2379651 1.0 Yes FUSE - 700 V, 200 A, FAST SEMI
15 2238207-3 1.0 Yes FUS FF 14X51 2A 700VDC C 50KA ULR
16 99183979 1.0 Yes SLOW BLOW FUSE HCP 6X32 10A 250V UL
Table 9-14 FUSE KIT BS 90KVA (2385412-2 BOM, rev 2)
