GE HEALTHCARE
D
IRECTION 5141177-100, REVISION 14 BRIGHTSPEED ELITE, EDGE, EXCEL: PRE-INSTALLATION
Chapter 9 - Interconnection Data Page 151
9 – Interconnects
Table 9-15 FUSE KIT for BSD Meri (2385412-4 BOM, rev 2)
17 U8009FF 2.0 Yes FUSE 3.2A
18 U8008FF 1.0 Yes FUSE 2.0A
19 U8006FF 2.0 Yes FUSE 1.0A
ITEM NUMBER QTY FRU CODE DESCRIPTION/NAME
Table 9-14 FUSE KIT BS 90KVA (2385412-2 BOM, rev 2) (Continued)
ITEM NUMBER QTY FRU CODE DESCRIPTION/NAME
1 2351493 1 Yes 100A 690V Semiconductor Fuse
2 2364059 1 Yes GLASS FUSE
3 46-170021P50 1 Yes FUSE, TIME DELAY, 6.3X32MM, 12A, 250V, 400A INTERRUPT AT
250VAC, CERAMIC, UL
4 46-170021P15 1 Yes FUSE, TIME DELAY, 6.3X32MM, 8A, 250V, 400A INTERRUPT AT
250VAC, CERAMIC, UL
5 2336517-2 1 Yes FUSE 25 AMPS 700 VOLTS 2.5M SECONDS
6 46-170021P52 5 Yes FUSE 3 AMPS 250 VOLTS (REVIEWED TK, 7-91).
7 46-170021P10 2 Yes 006.000A 0250V 3AG FAST UL/C (REVIEWED TK, 7/91).
8 46-170021P101 1 Yes FUSE 20 AMPS 700 VOLTS 2~ LONG X 9/16~ DIA FAST BLOW
9 46-170021P106 1 Yes FUSE 8 AMPS 250 VOLTS BUSSMANN ONLY
10 46-170021P31 2 Yes One-HalfA, 250V SLO-BLO FUSE. TYPE 3AG, 1.25aprox. X 0.25aprox.
GLASS BODY. REVIEWED TK, 7-91
11 5329469 2 Yes FUSE 20 AMPS 500 VOLTS .3 SECONDS--RoHS
12 46-327160P1 1 Yes 12.0A, 125VAC, DUAL ELEMENT TIME DLY FNM-12, 0.406 X 1.5 LG,
FIBER BODY
13 2379651 1 Yes FUSE - 700 V, 200 A, FAST SEMI
15 2238207-3 1 Yes FUS FF 14X51 2A 700VDC C 50KA ULR
16 99183979 1 Yes SLOW BLOW FUSE HCP 6X32 10A 250V UL
17 U8006FF 2 Yes FUSE 1.0A
18 5118644 1 Yes FAST ACTION 15 AMPS 250 VOLTS 0.01 SECONDS U0028FF
19 5327449 2 Yes PROTECTION FUSE, 3.2A, NA, FAST ACTION, 250V, HM FUSE
20 5327448-2 1 Yes PROTECTION FUSE, 2A, NA, FAST ACTION, 250V, HM FUSE, Not
Preferred Part
21 2374694 2 Yes 8A TIME DELAY FUSES
22 5368105 1 Yes 1A Time_Delay fuse,10_4X38_1CLIP
23 5306477-3 1 Yes PROTECTION FUSE, 15A, TIME DELAY, 300VDC, 600VAC, CARTRIDGE
