Page #70 background imageLoading...
Page #70 background image
GE HEALTHCARE
D
IRECTION 5141177-100, REVISION 14 BRIGHTSPEED ELITE, EDGE, EXCEL: PRE-INSTALLATION
Page 70 Section 5.0 - Recommended Layouts
control room area, and sometimes may be directly linked to the operator console.
Additional components although linked via network or ethernet cable, are not powered from
the CT operator console.
Additional room power and network connection should be considered when reviewing the
console work space.
5.2 Storage Cabinet
A storage cabinet is provided by GE Healthcare to store all supplied service equipment (see
Table 4-9 for equipment list). This storage cabinet (457 mm D x 914 mm W x 1067 mm H) (18 in.
D x 36in. W x 42in. H; ~90 lbs) should be located in the scan room suite area, for easy service
access. A storage Cabinet is provided as option (B77292CA)
5.3 Advantage Workstation (AW)
Refer to Advantage Workstation Pre-Installation Manual and Installation/Service Manual.
ITEM SIZE WEIGHT (TOTAL)
QA Phantom (water filled) 20 x 15 cm
(7.9 in. x 5.9 in. )
5.5 kg 12 lb
35CM Phantom 35 x 7 cm
(13.8 in. x 2.8 in. )
8.2 kg 18 lb
48CM Phantom 48 x 7 cm
(18.9 in. x 2.8 in.)
11.4 kg
25 lb
Phantom Holder 25 x 25 cm
(9.8 in. x 9.8 in.)
3.6 kg 8 lb
FE Box 30 x 38 x 30 cm
(11.8 in. x 15 in. x 11.8 in.)
6.8 kg 15 lb
Rear Cover Dollies 158 x 82 cm
(62.2 in. x 32.3 in.)
11.4 kg 25 lb
Front Cover Dollies 85 x 20 cm and 85 x 15 cm
(33.5 in. x 7.9 in. and 33.5 in. x
5.9 in.)
15.9 kg 35 lb
Install Support Kit (box) 30 x 30 x 38 cm
(11.8 in. x 11.8 in. x 15 in.)
9.1 kg 20 lb
Tube Hoist Kit 77 x 8 cm and 38 x 15 cm
(30.3 in. x 3.1 in. and 15 in. x
5.9 in.)
9.1 kg 20 lb
Balance Weight Kit 33 kg 73 lb
Table 4-9 Equipment to be stored in storage cabinet
