GE HEALTHCARE 

IRECTION 5141177-100, REVISION 14 BRIGHTSPEED ELITE, EDGE, EXCEL: PRE-INSTALLATION

Chapter 4 - Room Planning Page 71

4 – Room Planning

Section 6.0

Component Dimensions

6.1 Table and Gantry

Figure 4-7 Table and Gantry (Side View) for BSD Elite/Edge/Excel with HPower Table

DESCRIPTION WIDTH DEPTH HEIGHT

INCH MM INCH MM INCH MM

Color printer 23 584 18 457 7 178

Remote Color Monitor (LCD) 16.25 413 8 203 16 406

Table 4-10 Dimensions of Accessories

MM [INCHES]

2618 [103,1]

1060 [41,71]

1016 [40]

1930[76]

Note: Drawing is not to scale

AIR IN

AIR OUT

AIR IN

1930 [76]
