IRECTION 5141177-100, REVISION 14 BRIGHTSPEED ELITE, EDGE, EXCEL: PRE-INSTALLATION
Chapter 4 - Room Planning Page 75
4 – Room Planning
6.2 Power Distribution Unit
Figure 4-11 Power Distribution Unit (NGPDU)
Power Distribution Unit (NGPDU)
NOTE: DIMENSIONS ARE IN INCHES (MILLIMETERS).
REAR VENT AREA
41.8 (1062)
REAR VIEW
TOP VIEW
REAR
AC POWER
INPUT BOX
AC POWE
R
INPUT BOX
2.6 (67)
I/O CONNECTIONS
PANEL
FRONT
2
.4
(60)
27.6
(700)
21.7 (550)
NOTES:
DIMENSIONS ARE IN INCHES (MILLIMETERS).
INDICATES AIR FLOW (Convection):
SERVICE AREA
MINIMUM AIR FLOW CLEARANCE
5.9 (150)
41.8 (1062)
27.6
(700)
35.4 (900)
21.7 (550)
4.9 (125)
14.2
(360)
