IRECTION 5141177-100, REVISION 14 BRIGHTSPEED ELITE, EDGE, EXCEL: PRE-INSTALLATION
Page 76 Section 6.0 - Component Dimensions
6.3 Operator’s Console
Figure 4-12 Operator’s Console with Standard Table
705
DIM MIN MAX A 680 883 B 680 807 C 1020 1228 D 426 634
Air In
Air Out
Min 6" Clearance
Wall
