GE HEALTHCARE 
D
IRECTION 5141177-100, REVISION 14 BRIGHTSPEED ELITE, EDGE, EXCEL: PRE-INSTALLATION
Page 88 Section 9.0 - Network Connections
Figure 4-20 TIO Console and Host Computer Rear
To Advantage Workstation
if Hispeed connection is required
HOST COMPUTER REAR PANEL
ETHERNET PORTS
A SWITCH HUB
B HOSPITAL
C GANTRY
D BACKUP
USB PORTS
1 TRACKBALL
2 MOUSE
3 KEYBOARD
4 BARCODE
5 MODEM
6 TOWER DVD-R
7 TOWER DVD-RAM
8 TOWER EXTERNAL
HARDDISK
9 BACKUP
TIO Console Rear
TIO Host Computer Rear
