GE CB Watch 3 User Manual

CB Watch 3 User Manual v6.3 - May 2019 Page 11 of 100
In the window, select IPv4 IP address settings and click properties.
A new window (as shown below) will appear:
By default, the IP address of the CBW3 is set in the factory to: 192.168.5.22
But your particular IP address will have been set during the installation process. We will
use the default IP address here, purely as an example.
To communicate with the CBW3, you will need to set your network adapter to another
address on that network, for example: 192.168.5.30
The last number 30 could be between 1 and 254, with the exception of 22 (which is the
CBW3 address)
To do that, select “Use the following IP address” and enter:
- The IP address 192.168.5.30
- The sub-net mask 255.255.255.0
and then click OK
You can leave the DNS server settings blank
Figure 5 – Network card configuration step 3
Here is an example of a network connection layout. It is possible to have one or several
CBW3 connected on the same network in a substation.
Figure 6 – CBW3 network connections
