GE Dash 4000 Operator's Manual

11-6 Dash™ 3000/4000/5000 2000966-386D
Monitoring SpO2
WARNING
DATA VALIDITY—Do not expose sensor detector to strong
ambient light while monitoring a patient. A poor signal may result.
WARNING
DATA VALIDITY —Do not allow tape to block the sensor
photodetectors.
WARNING
PATIENT SAFETY—Prolonged monitoring may require changing
the sensor site periodically. Move the sensor if there is any sign of
skin irritation or impaired circulation. Change the sensor site at least
every four hours to prevent ischemic skin necrosis. Be particularly
careful when monitoring neonates. If required, reduce the
application periods to half the times recommended above. If a sensor
is damaged in any way, discontinue use immediately.
WARNING
APNEA —A pulse oximeter should NOT be used as an apnea “no
breath” monitor.
WARNING
CABLES—Route all cables away from the patient’s throat to avoid
possible strangulation.
WARNING
EARLY WARNING—A pulse oximeter should be considered an
early warning device. As a trend toward patient deoxygenation is
indicated, blood samples should be analyzed by a laboratory co-
oximeter to completely understand the patient’s condition.
WARNING
EXPLOSION HAZARD—Do not monitor SpO
2
in the presence of
flammable anesthetics or other flammable substance in combination
with air, oxygen-enriched environments, or nitrous oxide.

GE Dash 4000 Specifications

General

Resolution	640 x 480 pixels
Power Supply	100-240 VAC, 50/60 Hz
ECG	3/5/12-lead
IBP	Up to 4 channels
Battery Backup	Yes
Certifications	CE, UL, CSA
Parameters Monitored	ECG, SpO2, NIBP, IBP, Temperature, Respiration, Cardiac Output
Connectivity	Ethernet, USB, Serial
Display Type	TFT LCD
Recorder	Integrated thermal printer
Battery Type	Lithium-ion
Operating Temperature	0 to 40°C
Storage Temperature	-20 to 60°C
Humidity Range	15% to 95% non-condensing
Display Size	10.4 inches
Cardiac Output	Available
