GE Dash 4000 Operator's Manual

7-4 Dash™ 3000/4000/5000 2000966-386D
Printing
Guidelines
Keep in mind the following printing guidelines:
 When printing to a laser printer, there may be a slight (one minute) delay to print
the first page of data when any speed slower than 25 mm/sec is selected. Each
page contains 20 seconds of waveforms per page in a cascade format.
 If the selected printer is removed from use, you must update the location to an
available printer. All failed print jobs are saved until a printer is available. They
print as soon as a functioning printer is selected.
 A one millivolt ECG signal at normal (1X) size equals 10 millimeters on the
graph paper.
 To convert an arrhythmia alarm to a manual print, stop the print job by pressing
the Graph Go/Stop or Print key and immediately restart by pressing the Graph
Go/Stop or Print key again.
 Invasive pressure scales print on individual and full scales as follows:
Displayed Scale Printed Scale
30 0-30 (PA, CVP, LA, RA, ICP)
40 0-45
60 0-60
100 0-90
160 0-150
200, 300 0-300
Auto 0-150 (ART, FEM, UAC, SP)
0-45 (PA, CVP, UVC, LA, RA, ICP)

GE Dash 4000 Specifications

General

Resolution	640 x 480 pixels
Power Supply	100-240 VAC, 50/60 Hz
ECG	3/5/12-lead
IBP	Up to 4 channels
Battery Backup	Yes
Certifications	CE, UL, CSA
Parameters Monitored	ECG, SpO2, NIBP, IBP, Temperature, Respiration, Cardiac Output
Connectivity	Ethernet, USB, Serial
Display Type	TFT LCD
Recorder	Integrated thermal printer
Battery Type	Lithium-ion
Operating Temperature	0 to 40°C
Storage Temperature	-20 to 60°C
Humidity Range	15% to 95% non-condensing
Display Size	10.4 inches
Cardiac Output	Available
