GE Dash 4000 Operator's Manual

Equipment Overview
2000966-386D Dash™ 3000/4000/5000 2-3
NOTE
All patient connectors with the applied part symbol ( ) are high-insulation
ports and defibrillator proof to ensure patient safety and protect the device during
defibrillation and electrosurgery
Left
1 Patient connectors Allows patient cables to connect to the monitor.
2 Enabled option labels Identifies the options enabled on the monitor.
1 Built-in writer Prints on two inch wide paper.
2 Battery doors Holds up to two batteries to provide power during patient
transport or whenever AC power is interrupted. For more
information, refer to Batteries on page A-7.
1
2
4000

GE Dash 4000 Specifications

General

Resolution	640 x 480 pixels
Power Supply	100-240 VAC, 50/60 Hz
ECG	3/5/12-lead
IBP	Up to 4 channels
Battery Backup	Yes
Certifications	CE, UL, CSA
Parameters Monitored	ECG, SpO2, NIBP, IBP, Temperature, Respiration, Cardiac Output
Connectivity	Ethernet, USB, Serial
Display Type	TFT LCD
Recorder	Integrated thermal printer
Battery Type	Lithium-ion
Operating Temperature	0 to 40°C
Storage Temperature	-20 to 60°C
Humidity Range	15% to 95% non-condensing
Display Size	10.4 inches
Cardiac Output	Available
