Factory Defaults
2000966-386D Dash™ 3000/4000/5000 C-11
Default Parameter Priority
The following are the parameter priority factory defaults. To access these options,
select MORE MENUS > MONITOR SETUP > MONITOR DEFAULTS > SETUP
DEFAULT PARAMETER PRIORITY.
The following parameters, when monitored, always appear in the parameter window.
The following highlighted parameters’ parameter windows may display on the
bottom of the screen when there is no room on the right side of the screen. The
parameters preceded with an asterisk (*) may display in reduced size.
Adult-ICU
BIS SMOOTH
RATE
15 SEC
EEG WF SCALE 25
EEG WF SPEED 25
AUTO ADMIT ON
ADULT-ICU NEONATAL-ICU
OPERATING
ROOM
ADULT-ICU NEONATAL-ICU
OPERATING
ROOM
PARAMETER 1
1
1
When ECG is turned on, it is first and cannot be changed. If turned off, SPO2 is first and
cannot be changed.
ECG ECG ECG
PARAMETER 2 ECG UAC NBP
PARAMETER 3 ART UVC ART
PARAMETER 4 PA RR PA
PARAMETER 5 SPO2 SPO2 SPO2
PARAMETER 6 CO2 NBP CO2
GAS CVP* CO* BIS
NBP RA* CCO
ART UVC*
RESP
FEM LA* TEMP*
UAC ICP* TC
PA SP* UO*

GE Dash 4000 Specifications

General

Resolution	640 x 480 pixels
Power Supply	100-240 VAC, 50/60 Hz
ECG	3/5/12-lead
IBP	Up to 4 channels
Battery Backup	Yes
Certifications	CE, UL, CSA
Parameters Monitored	ECG, SpO2, NIBP, IBP, Temperature, Respiration, Cardiac Output
Connectivity	Ethernet, USB, Serial
Display Type	TFT LCD
Recorder	Integrated thermal printer
Battery Type	Lithium-ion
Operating Temperature	0 to 40°C
Storage Temperature	-20 to 60°C
Humidity Range	15% to 95% non-condensing
Display Size	10.4 inches
Cardiac Output	Available
