Equipment Overview
2000966-386D Dash™ 3000/4000/5000 2-11
Dash Port 2
The Dash Port 2 is a docking station for a monitor. It gives the monitor easy connect/
disconnect access to AC power, the network, remote display and auxiliary devices.
For more information, refer to the docking station operating instructions.
Remote Display
The remote display provides a larger display or display in a separate room. The
remote display must be located within 150 feet of the patient monitor. It also requires
a docking station, a monitor running software version 5 or later and a network
connection.
Cardiac Output Adult and Operating Room Opens the CARDIAC OUTPUT menu.
CRG Events Neonatal Opens the DOCUMENT CRG EVENTS window.
CRG Print Neonatal Prints the CRG waveforms.
CRG Recall Neonatal Opens the CRG TRENDS menu at the most recent CRG event.
Defaults Adult, Neonatal and Operating Room Opens the MONITOR DEFAULTS menu.
Display On/Off Adult, Neonatal and Operating Room Turns the display, alarms and NBP off, but remaining on AC or
battery power and active at the central station.
Dose Calcs Neonatal Opens the DOSE CALCS menu.
Graph Go/Stop Print Adult, Neonatal and Operating Room Prints the current patient data. Press again to stop.
Graphic Trends Adult and Operating Room Opens the GRAPHICS TRENDS menu.
Main Menu Adult, Neonatal and Operating Room Returns to the main display.
NBP Auto Adult and Operating Room Opens the NBP AUTO menu.
NBP Go/Stop Adult, Neonatal and Operating Room Begins an NBP measurement. Press again to stop.
NBP Stat Adult and Operating Room Starts five minutes of continuous, sequential NBP measurements.
New Case Operating Room Discharges and admits a patient.
PA Wedge Adult and Operating Room Opens the PA WEDGE menu.
QRS Volume Neonatal Opens a menu to adjust the QRS volume tone.
Resp Relearn Neonatal Relearns the patient’s respiration.
Silence Alarm Adult, Neonatal and Operating Room Silences sounding alarms.
SpO2 Operating Room Opens the SPO
2
menu.
View Other Adult and Neonatal Opens the VIEW OTHER PATIENTS menu.
Vital Signs Adult and Neonatal Opens the VITAL SIGNS menu.
Zero All Adult, Neonatal and Operating Room Zeroes all invasive pressure lines open to the atmosphere.
Button Version Function
