GE DigitalFlow DF868 User Manual

March 2008
1-8 Programming Site Data
Entering Programming
Mode
Use the keypad, as described in Chapter 3, Operation, of the Startup
Guide to navigate through the User Program. The menu map may be
followed in sequence, or the [↑] and [↓] keys may be used to scroll
through the prompt screens. The [←] key may be used to delete the
last alphanumeric character that was entered from the keypad.
The following discussion assumes that the left screen pane is active.
If the right screen pane is active, only the function key designations
change. That is, replace
[F1]-[F4] with [F5]-[F8]. Also, Channel 1 is used
in all examples, but the instructions apply equally to
Channel 2.
Note: Be sure to record all the programming data entered in this
chapter in Appendix B, Data Records.
Programming of the
ACTIV, SYSTM (CH1/2 and GLOBL) and PIPE
submenus is necessary for operation of the Model DF868. Failure to
accurately enter all of the required information will result in
unreliable flow rate data. Therefore, be sure to complete at least the
sections of this chapter pertaining to those three submenus.
Note: Because it is so essential, instructions for programming the
ACTIV, SYSTM and PIPE submenus are also included in the
Startup Guide. If that programming has already been
completed, skip the corresponding sections of this chapter.
Except for the three submenus noted above, it is not necessary to
program the Model DF868 flowmeter in any particular order.
Therefore, the sections of this chapter need not be completed in
sequence. Proceed immediately to any section of interest.
Entering Programming
Mode
To access the User Program, press the [PROG] key on the keypad. The
standard measurement mode screen will be replaced by the following
initial programming mode screen:
Note: If the security feature is active, enter the password and press
the
[ENT] key to enter the User Program. See the SECUR
submenu section of this chapter on page 1-63 for more
information on the security feature.
PROGRAM Start ‰
Press the [←] and [→] keys and
one of the function keys
[F1]-[F4]
to select the desired submenu.
From this screen, press
[EXIT] to
return to measurement mode.
PROGRAM
Channel 1
CH1 CH2 GLOBL SAVE
