256 PMCS Interface Toolkit
#1 #2 #3 & #4 Sliding Window Key Thumbwheel Settings
Class Sub-
class
Instance Measurement Supported Modes
4 3 00 Volts LN Average HS STD TD SD PD
4 3 01 Volts LN Phase A HS STD TD SD PD
4 3 02 Volts LN Phase B HS STD TD SD PD
4 3 03 Volts LN Phase C HS STD TD SD PD
4 3 04 Volts LL Average HS STD TD SD PD
4 3 05 Volts LL Phase AB HS STD TD SD PD
4 3 06 Volts LL Phase BC HS STD TD SD PD
4 3 07 Volts LL Phase CA HS STD TD SD PD
4 3 08 Amps Average HS STD TD SD PD
4 3 09 Amps Phase A HS STD TD SD PD
4 3 0A Amps Phase B HS STD TD SD PD
4 3 0B Amps Phase C HS STD TD SD PD
4 3 0C Amps Neutral HS STD TD SD PD
43 0D Reserved
4 3 0E Volts Imbalance (0-100) HS STD TD SD PD
4 3 0F Amps Imbalance (0-100) STD TD SD PD
4 3 10 kW Total HS STD TD SD PD HRS
4 3 11 kW Phase A HS STD TD SD PD
4 3 12 kW Phase B HS STD TD SD PD
4 3 13 kW Phase C HS STD TD SD PD
4 3 14 kVAR Total STD TD SD PD HRS
4 3 15 kVAR Phase A STD TD SD PD
4 3 16 kVAR Phase B STD TD SD PD
4 3 17 kVAR Phase C STD TD SD PD
4 3 18 kVA Total HS STD TD SD PD HRS
4 3 19 kVA Phase A HS STD TD SD PD
4 3 1A kVA Phase B HS STD TD SD PD
4 3 1B kVA Phase C HS STD TD SD PD
4 3 1C PF Total STD TD SD PD
4 3 1D PF Phase A STD TD SD PD
4 3 1E PF Phase B STD TD SD PD
4 3 1F PF Phase C STD TD SD PD
4 3 20 Frequency HS STD TD SD PD
4 3 21-23 Reserved
4 3 24 Phase Reversal (0 or 1) HS STD
4 3 25-27 Reserved
4 3 28 VAUX STD TD SD PD
