FP1500 Installation, Configuration and Commissioning Manual 31
[EVENTS] [# Exit]
1. General
2. Logical
In option 1 <General Events> allocate a
number to the <Fault Event> (e.g. [004]).
Fault Event : [004]
Pre-Alarm Event : [000]
Recognised Event : [000]
[CONFIGURE] [# Exit]
1. System 4. System Op. 7. Events
2. See Config. 5. Check Prog. 8. Day Mode
3. Time/Date 6. Power Supply 9. Codes
Now return to [SYSTEM] and enter option 8
<Relays>.
[SYSTEM] [# Exit]
1. Loop 1 4. Loop 4 7. Sirens
2. Loop 2 5. Loop 5 8. Relays
3. Loop 3 6. Peripherals 9. PC
Press < 9 > screen [RELAY1] or [RELAY2]
allocate the same event number to [Event-1]
(e.g. [004]) and set Initial Mode [Inverse]
RELAY 1:
Logic line: [001] With Evacuation: NO]
Event-1: [000] Initial Mode: [NORMAL]
Event-2: [000]
RELAY 1:
Logic line: [001] With Evacuation: [NO]
Event-1: [004] Initial Mode: [INVERSE]
Event-2: [000]
4.2 Configuration with advanced options
4.2.1 Day mode setting
The control unit can be pre-programmed to operate in certain ways at certain times of the
day:
Delayed day mode
The control unit can be configured to delay the triggering of outputs in any zone. During
the allocated delay period, the control unit receives an alarm warning. A complete fire
condition is executed if no action is executed in a time specified as a response to the
warning.
Configuration Delayed day mode
[CONFIGURE] [# Exit]
1. System 4. System Op. 7. Events
2. See Config. 5. Check Prog. 8. Day Mode
3. Time/Date 6. Power Supply 9. Codes
Proceed as follows:
1. From the main menu, access option 1
<Configure> and from there, type in
option 8 <Day mode>
[DAY MODE] [# Exit]
1. Delayed Mode
2. Sensitivity Mode
Allow Mode : [NO]
Start Time : [00:00] End Time: [00:00]
Alert 1 : [010] Secs Delay
Alert 2 : [030] Secs Delay
2. Select: point 1 <Delayed Mode> and an
information screen appears. This screen
must receive two alerts before the control
unit triggers the full alarm.
1
1
1
8
8
1
