FP1500 Installation, Configuration and Commissioning Manual 35
LANGUAGE
A
DDRES
S
SPANISH
ITALIAN
PORTUGUESE
ENGLISH
Output to the next element
configuration of the address and the language is made through micro-switches on the
bottom of the main board of the repeater.
These are the combinations for defining the address and language:
Combinations for defining the address and language of the FP1500R repeaters
Once the address has been set, perform the auto-search for peripherals from the master
control unit to configure all the elements installed on the network through the RS485 port.
Figure 16. FR1500 repeater
Figure 17. Repeater to control unit connection diagram
4.2.5 Connection of a modem
The analogue fire detection system allows the connection of a GSM modem. This allows
sending of short text messages to mobile phones. In this way, fault or alarm messages
that appear on the screen of the control unit are sent to pre-programmed phones.
