FP1500 Installation, Configuration and Commissioning Manual 42
Press: <ENTER>
The panel will indicates on what code number
(between 01 and 10) the code is allocated.
Write a 4-digit access code.
E.g. From [01] to [05] : [1234]
In this way, we only have 5 codes to allocate,
since the first five have the access code [1234]
If all ten codes are required:
From [01] to [01] : [1111]
From [02] to [02] : [2222]... etc.
LEVEL CODES: [2]
From [01] to [01] Value: [ ]
Duration: [05] Minutes
Duration:
This parameter may be modified as required.
Normally, if after pressing any key on the
control unit no further action is taken, after the
programmed time (e.g. 05 minutes), the control
unit will ask for the access code again.
This ensures that only authorised personnel
use the control unit.
LEVEL CODES: [3]
LEVEL CODES: [3]
Current Code: [0000]
New Code: [0000]
On level 3: key in <3>
On this level, only one code exists.
The control unit has the code: [9898] factory
setting, but this can be changed.
<ENTER> the control unit requires the current
code and then you may type in the new code.
The code is changed from this moment on.
Write down your access code and save it in a safe place.
4.3 Graphics software
The FP1500 analogue fire detection system has additional software that enables the
management and control of the installation via PC.
This software is made up of three components:
• Plan Editor: a tool for creating a diagrammatic plan with the situation of each of the
components of the system in the installation. In this way, the identification in the
event of an alarm is faster and more efficient.
• Events Viewer: record of the graphics software. It draws up a list of all the
movements made on the control unit.
• User application: once the control unit has been configured and the installation plan
has been edited, this application enables full visual control of the system. Please ask
your distributor for more information.
