5 POWER
The product is wired directly to the mains so is continually powered on. The mains fuse
holder for the product is shown in Figure 5-1 and is located towards the bottom right-hand
side of the Hub module.
Figure 5-1: Fuse holder
The product uses four external sunlight-visible LEDs on the front door. Each LED has two
states – ‘Off’ (-) or ‘On’ as outlined in Table 5-1.
Table 5-1: External LED status indicators
