Maintenance
6.InserttheO-Ringintothegrooveonthetopcover,asshowninthefollowing
photograph.
7.Alignthetabsonthedisplaybottomcoverwiththeslotsonthedevicetopcover,
asindicatedinthefollowingphotograph.
8.Lowerthedisplaybottomcovertothedevicetopcoverandcarefullythreadthe
displaycableandkeypadribbonthroughtheslotsonthetopcover.
9.Slidethedisplayassemblytowardthebackofthetopcover,indicatedbythe
arrowonthefollowingphotograph,toreattachittothetopcover.
10.Turnoverthetopcoverassemblyandsecurethedisplayassemblytothetop
coverusingthesixfastenersshowninthefollowingphotograph.
