GE MFE DMS 2 User Manual

Appendix B. Choosing the File Type
Page 198 DMS 2 Operating Manual
BOILER File
Data file format with 3 structure elements (ELEVATION, TUBE, and POINT); especially for inspecting boilers and other structures
with 2 identifying levels.
STRUCTURE:
ELEVATION 1
TUBE 1 TUBE
n
ELEVATION 2
TUBE 1 TUBE
n
ELEVATION k
TUBE 1 TUBE
n
Point 1 Point n
EACH ELEVATION MUST BE GIVEN A NAME BY THE USER
EACH ELEVATION WILL HAVE THE SAME NUMBER OF POINTS AS SET BY THE USER WHEN FILE IS CREATED
BOILER
NUMBER OF POINTS SAME ON EACH TUBE
