DDB Signal
Name
DDB Signal
Number
Source Module Destination Module
CB Closed 3 ph 907 CB State Monitor (1)
CB In Service
CB Autoclose
AR In Progress
Evolving Fault
Reclaim Time
Successful AR Signals
CB Healthy and System Check Timers
CB Control
CB Trip Time Monitor
CB Closed A ph 908 CB State Monitor (1) CB Control
CB Closed B ph 909 CB State Monitor (1) CB Control
CB Closed C ph 910 CB State Monitor (1) CB Control
CB Control 1566 CB Autoclose (32)
CB Fail Pr Trip 1575 CB Trip Time Monitor (53) Autoreclose Lockout
CB Failed AR 1550 Evolving Fault (20)
CB Fast SCOK 1572 3 Phase AR System Check (45)
CB Autoclose
Prepare Reclaim Initiation
CB Healthy and System Check Timers
CB Healthy 436
CB Autoclose
CB Healthy and System Check Timers
CB Control
CB In Service 1526 CB In Service (4)
AR OK
Autoreclose Lockout
CB Man SCOK 1574
3 Phase AR System Check (45)
CB Manual Close System Check (51)
CB Control
CB NoAR 1528 AR OK (8) AR In Progress
CB Open 3 ph 903 CB State Monitor (1)
CB Open
Dead Time Start Enable
CB Autoclose Logic
CB Control
CB Trip Time Monitor
CB Open A ph 904 CB State Monitor (1)
CB Open
CB Control
Pole Discrepancy
CB Open B ph 905 CB State Monitor (1)
CB Open
CB Control
Pole Discrepancy
CB Open C ph 906 CB State Monitor (1)
CB Open
CB Control
Pole Discrepancy
CB SCOK 1573 3 Phase AR System Check (45)
CB Autoclose
Prepare Reclaim Initiation Logic
CB Healthy and System Check Timers
CB Status Alarm 301 CB State Monitor (1)
CB Succ 1P AR 1571 Successful AR Signals (36) AR Shot Counters
CB Succ 3P AR 852 Successful AR Signals (36) AR Shot Counters
CB Trip Fail 302 CB Control (43)
Check Sync 1 OK 883 Check Sync Signals (60)
3 Phase AR System Check
CB Manual Close System Check
P543i/P545i Chapter 11 - Autoreclose
P54x1i-TM-EN-1 313
