DDB Signal
Name
DDB Signal
Number
Source Module Destination Module
Check Sync 2 OK 884 Check Sync Signals (60)
3 Phase AR System Check
CB Manual Close System Check
Close in Prog 842 CB Control (43)
Control Close 839 CB Control (43)
Control Trip 838 CB Control (43) CB Control
CS AngRotACW 1594 Check Sync Signals (60)
CS AngRotCW 1595 Check Sync Signals (60)
CS1 SlipF> 1578 Check Sync Signals (60)
CS1 SlipF< 1579 Check Sync Signals (60)
CS VBus< 1583 Check Sync Signals (60)
CS VBus> 1582 Check Sync Signals (60)
CS VLine< 1580 Check Sync Signals (60)
CS VLine> 1581 Check Sync Signals (60)
CS1 AngHigh- 1593 Check Sync Signals (60)
CS1 AngHigh+ 1592 Check Sync Signals (60)
CS1 FL<FB 1591 Check Sync Signals (60)
CS1 FL>FB 1590 Check Sync Signals (60)
CS1 VL<VB 1588 Check Sync Signals (60)
CS1 VL>VB 1586 Check Sync Signals (60)
CS2 AngHigh- 1496 Check Sync Signals (60)
CS2 AngHigh+ 1495 Check Sync Signals (60)
CS2 FL<FB 1494 Check Sync Signals (60)
CS2 FL>FB 1493 Check Sync Signals (60)
CS2 SlipF< 1465 Check Sync Signals (60)
CS2 VL<VB 1589 Check Sync Signals (60)
CS2 VL>VB 1587 Check Sync Signals (60)
Dead Bus 887 System Checks Voltage Monitor (59)
3 Phase AR System Check
CB Manual Close System Check
Dead Line 889 System Checks Voltage Monitor (59)
Dead Time Start Enable
3 Phase AR System Check
CB Manual Close System Check
DTOK All 1551 Dead Time Start Enable (22)
1-phase AR Dead Time
3-phase AR Dead Time Enable
DTOK CB 1P 1552 Dead Time Start Enable (22) 1-phase AR Dead Time
DTOK CB 3P 1553 Dead Time Start Enable (22) 3-phase AR Dead Time Enable
Evolve 3Ph 1547 Evolving Fault (20)
3-phase AR cycle selection
Autoreclose Lockout
Ext CS OK 900
3 Phase AR System Check
CB Manual Close System Check
Ext Fault Aph 1508 Fault Memory
Ext Fault BPh 1509 Fault Memory
Ext Fault CPh 1510 Fault Memory
Ext Rst AROK 1517 AR Reset Successful Logic
Ext Rst CB Shots 1518 AR Shot Counters
Chapter 11 - Autoreclose P543i/P545i
314 P54x1i-TM-EN-1
