1.4 Mini Field Agent (MFA)
The GE Mini Field Agent* (MFA) module is a Machine to Cloud collector that securely forwards data to a Predix* Time
Series Database Service. The MFA is based on the ARM architecture and designed to meet low power, harsh environment
specifications for industrial use. It runs an embedded Linux® operating system and comes with Predix Machine pre-integrated
and ready to enroll in Predix EdgeManager. The Field Agent ecosystem enables end users ease of developing Predix solutions
using the MFA platform. The following figure depicts the typical installation of a MFA. The section Configure the Network
provides defaults IP addresses.
Features
• Predix Machine
• One Wide Area Network (WAN) Ethernet port
• Three Local Area Network (LAN) Ethernet ports with
built-in switch
• RS-485 hardware interface
• RS-232 hardware interface
• CAN bus hardware interface
• One discrete input
• One relay contact
• Optional cellular modem
• Optional Wi-Fi hotspot
Discrete
Input/Relay
Switched 10/100 Mbps
Ethernet Ports
Power Supply
RS-485 and CAN bus
Serial Com Ports
RS-232 Serial
Com Ports
