MM2 Motor Manager 2 6-25
6 COMMUNICATIONS 6.5 MEMORY MAP
6
USER
DEF.
DATA
con’t
30267 266 010A User Definable Data 000A
30268 267 010B User Definable Data 000B
30269 268 010C User Definable Data 000C
30270 269 010D User Definable Data 000D
30271 270 010E User Definable Data 000E
30272 271 010F User Definable Data 000F
↓↓↓ ↓ ↓ ↓ ↓↓ ↓
30376 375 0177 User Definable Data 0077
Setpoint Values (Holding Registers) Addresses - 1000-1FFF
MOTOR
ID
44097 4096 1000 Motor Name characters 1 and 2 32-127 1 ASCII F10 "MO"
44098 4097 1001 Motor Name characters 3 and 4 32-127 1 ASCII F10 "TO"
44099 4098 1002 Motor Name characters 5 and 6 32-127 1 ASCII F10 "R "
44100 4099 1003 Motor Name characters 7 and 8 32-127 1 ASCII F10 " "
44101 4100 1004 Motor Name characters 9 and 10 32-127 1 ASCII F10 " "
44102 4101 1005 Motor Name characters 11 and 12 32-127 1 ASCII F10 " "
44103 4102 1006 Motor Name characters 13 and 14 32-127 1 ASCII F10 " "
44104 4103 1007 Motor Name characters 15 and 16 32-127 1 ASCII F10 " "
44105 4104 1008 Motor Name characters 17 and 18 32-127 1 ASCII F10 " "
44106 4105 1009 Motor Name characters 19 and 20 32-127 1 ASCII F10 " "
44107 4106 100A Motor Power Rating 3-11001 1 0.1 xkW F1* 65535 = OFF
44108 4107 100B High Speed Motor Power Rating 3-11001 1 0.1 xkW F1* 65535 = OFF
44109 4108 100C System Supply Voltage 110-600 1 V F1 480
44110 4109 100D ...Reserved... ... ... ... ... ...
44111 4110 100E ...Reserved... ... ... ... ... ...
44112 4111 100F ...Reserved... ... ... ... ... ...
STARTER 44113 4112 1010 Starter Type 0-11 1 --- F11 0 = OFF
44114 4113 1011 Change-over Current 10-51 1 0.1 xFLC F1* 15 = 1.5 xFLC
44115 4114 1012 Change-over Time 1-100 1 s F1 30
44116 4115 1013 Transfer Time 1-125 1 s F1 10
44117 4116 1014 Ramp Up Time 1-125 1 s F1 5
44118 4117 1015 Ramp Down Time 1-125 1 s F1 5
44119 4118 1016 Stage One Shorting Time 1-125 1 s F1 5
Table 6–12: MODBUS MEMORY MAP (Sheet 6 of 21)
GROUP MOD-
ICON
REGISTER
ADDRESS DESCRIPTION REGISTE
R VALUE
RANGE
STEP
VALUE
UNITS
AND
SCALE
FOR-
MAT
FACTORY
DEFAULT
VALUE
(CONVERTED)
DEC HEX
Notes: * – Maximum setpoint value and 65535 represent OFF
** – 1/Phase Current Scale Factor x A
*** – 101 represents unlimited
† – Minimum setpoint value represents OFF
~* – 0.1 x A when Hi resolution mode is disabled; 0.01 x A when enabled
