6-26 MM2 Motor Manager 2
GE Power Management
6.5 MEMORY MAP 6 COMMUNICATIONS
6
STARTER
continued
44120 4119 1017 Changeover Time 1-125 1 s F1 5
44121 4120 1018 Reserved
44122 4121 1019 Starts per Hour 1-41 1 s F1* 5
44123 4122 101A High Speed Start Block 0-1 1 -- F14 0 = DISABLE
44124 4123 101B Contactor Sequence 0-1 1 -- F32 0 = 1S-2S
44125 4124 101C ...Reserved... ... ... ... ... ...
↓↓↓ ↓ ↓ ↓ ↓↓ ↓
44128 4127 101F ...Reserved... ... ... ... ... ...
CT/VT
INPUTS
44129 4128 1020 Phase CT Primary 0-1000 5 A F1
†
0 = OFF
44130 4129 1021 High Speed Phase CT Primary 5-1000 5 A F1 100
44131 4130 1022 Ground CT Primary 5-1000 5 A F1 100
44132 4131 1023 Ground Fault CT 0-2 1 --- F13 0=50:0.025
44133 4132 1024 VT Primary Voltage 110-601 1 --- F1* 601 = OFF
44134 4133 1025 VT Connection Type 0-1 1 --- F15 0=PHS (A-N)
44135 4134 1026 VT Secondary Voltage 110-120 10 V F1 120
44136 4135 1027 Nominal Frequency 50-60 10 Hz F1 60
THERMIS-
TOR
44137 4136 1028 Cold Resistance 1-300 1 0.1 x kW F1 1 = 0.1 kW
44138 4137 1029 Hot Resistance 1-300 1 0.1 x kW F1 50 = 5.0 kW
44139 4138 102A Thermistor Trip 0-1 1 --- F14 0 = DISABLE
44140 4139 102B Thermistor Alarm 0-1 1 --- F14 0 = DISABLE
44141 4140 102C ...Reserved... ... ... ... ... ...
44142 4141 102D ...Reserved... ... ... ... ... ...
44143 4142 102E ...Reserved... ... ... ... ... ...
44144 4143 102F ...Reserved... ... ... ... ... ...
FAULT
MODE
44145 4144 1030 Internal Fault Trip 0-1 1 --- F14 1 = ENABLE
44146 4145 1031 Serial Comms Failure Trip 5-30 5 --- F1* 30 = OFF
44147 4146 1032 Serial Comms Failure Alarm 5-30 5 --- F1* 30 = OFF
44148 4147 1033 Change command mode on Alarm 0-1 1 --- F14 0 = DISABLE
44149 4148 1034 ...Reserved... ... ... ... ... ...
↓↓↓ ↓ ↓ ↓ ↓↓ ↓
44152 4151 1037 ...Reserved... ... ... ... ... ...
Table 6–12: MODBUS MEMORY MAP (Sheet 7 of 21)
GROUP MOD-
ICON
REGISTER
ADDRESS DESCRIPTION REGISTE
R VALUE
RANGE
STEP
VALUE
UNITS
AND
SCALE
FOR-
MAT
FACTORY
DEFAULT
VALUE
(CONVERTED)
DEC HEX
Notes: * – Maximum setpoint value and 65535 represent OFF
** – 1/Phase Current Scale Factor x A
*** – 101 represents unlimited
† – Minimum setpoint value represents OFF
~* – 0.1 x A when Hi resolution mode is disabled; 0.01 x A when enabled
