6-36 MM2 Motor Manager 2
GE Power Management
6.5 MEMORY MAP 6 COMMUNICATIONS
6
PROG.
MESSAGE
44481 4480 1180 Programmable msg chars 1 and 2 32-255 1 ASCII F10 "PR"
44482 4481 1181 Programmable msg chars 3 and 4 32-255 1 ASCII F10 "OG"
44483 4482 1182 Programmable msg chars 5 and 6 32-255 1 ASCII F10 "RA"
44484 4483 1183 Programmable msg chars 7 and 8 32-255 1 ASCII F10 "MM"
44485 4484 1184 Programmable msg chars 9 and 10 32-255 1 ASCII F10 "AB"
44486 4485 1185 Programmable msg chars 11 & 12 32-255 1 ASCII F10 "LE"
44487 4486 1186 Programmable msg chars 13 & 14 32-255 1 ASCII F10 " M"
44488 4487 1187 Programmable msg chars 15 & 16 32-255 1 ASCII F10 "ES"
44489 4488 1188 Programmable msg chars 17 & 18 32-255 1 ASCII F10 "SA"
44490 4489 1189 Programmable msg chars 19 & 20 32-255 1 ASCII F10 "GE"
44491 4490 118A Programmable msg chars 21 & 22 32-255 1 ASCII F10 "SA"
44492 4491 118B Programmable msg chars 23 & 24 32-255 1 ASCII F10 "MP"
44493 4492 118C Programmable msg chars 25 & 26 32-255 1 ASCII F10 "LE"
44494 4493 118D Programmable msg chars 27 & 28 32-255 1 ASCII F10 " T"
44495 4494 118E Programmable msg chars 29 & 30 32-255 1 ASCII F10 "EX"
44496 4495 118F Programmable msg chars 31 & 32 32-255 1 ASCII F10 "T "
44497 4496 1190 Programmable msg chars 33 & 34 32-255 1 ASCII F10 " "
44498 4497 1191 Programmable msg chars 35 & 36 32-255 1 ASCII F10 " "
44499 4498 1192 Programmable msg chars 37 & 38 32-255 1 ASCII F10 " "
44500 4499 1193 Programmable msg chars 39 & 40 32-255 1 ASCII F10 " "
44501 4500 1194 ...Reserved... ... ... ... ... ...
44502 4501 1195 ...Reserved... ... ... ... ... ...
44503 4502 1196 Default Message 1 Line Number 0-65535 1 --- F1 3
44504 4503 1197 Default Message 2 Line Number 0-65535 1 --- F1 0
44505 4504 1198 Default Message 3 Line Number 0-65535 1 --- F1 0
44506 4505 1199 Default Message 4 Line Number 0-65535 1 --- F1 0
44507 4506 119A Default Message 5 Line Number 0-65535 1 --- F1 0
PREFER-
ENCES
44508 4507 119B Display Brightness 0-100 20 % F1 60%
44509 4508 119C ...Reserved... ... ... ... ... ...
↓↓↓ ↓ ↓ ↓ ↓↓ ↓
44512 4511 119F ...Reserved... ... ... ... ... ...
Table 6–12: MODBUS MEMORY MAP (Sheet 17 of 21)
GROUP MOD-
ICON
REGISTER
ADDRESS DESCRIPTION REGISTE
R VALUE
RANGE
STEP
VALUE
UNITS
AND
SCALE
FOR-
MAT
FACTORY
DEFAULT
VALUE
(CONVERTED)
DEC HEX
Notes: * – Maximum setpoint value and 65535 represent OFF
** – 1/Phase Current Scale Factor x A
*** – 101 represents unlimited
† – Minimum setpoint value represents OFF
~* – 0.1 x A when Hi resolution mode is disabled; 0.01 x A when enabled
