6-44 MM2 Motor Manager 2
GE Power Management
6.6 DATA FORMATS 6 COMMUNICATIONS
6
F23 Unsigned Integer: Keypress
Simulation Data
FFFF
0x3100 = SETPOINT ---
0x3200 = ACTUAL ---
0x3300 = RESET ---
0x3400 = STORE ---
0x3500 = MESSAGE UP ---
0x3600 = MESSAGE DOWN ---
0x3700 = MESSAGE LEFT ---
0x3800 = MESSAGE RIGHT ---
0x3900 = VALUE UP ---
0x6100 = VALUE DOWN ---
F24 Unsigned Integer: Current key press FFFF
0000 = no key ---
FE01 = AUTO ---
FE02 = MANUAL ---
FE04 = START A ---
FE08 = START B ---
FD01 = STOP 1 ---
FD02 = STOP 2 ---
FD04 = RESET ---
FD08 = STORE ---
FB01 = SETPOINT ---
FB02 = ACTUAL ---
FB04 = MESSAGE UP ---
FB08 = MESSAGE DOWN ---
F701 = MESSAGE LEFT ---
F702 = MESSAGE RIGHT ---
F704 = VALUE UP ---
F708 = VALUE DOWN ---
F25 Unsigned Integer: Modbus Baud Rate FFFF
0 = 1200 ---
1 = 2400 ---
2 = 4800 ---
3 = 9600 ---
4 = 19200 ---
Table 6–13: DATA FORMATS (Sheet 7 of 15)
CODE DESCRIPTION BITMASK
F26 Unsigned Integer: Relay / LED Test
Data
FFFF
0 = Normal operation mode ---
1 = Contactor A On ---
2 = Contactor B On ---
3 = AUX Relay 1 On ---
4 = AUX Relay 2 On ---
5 = All Relays On ---
6 = Running LED On ---
7 = Stopped LED On ---
8 = Tripped LED On ---
9 = Alarm LED On ---
10 = Fault LED On ---
11 = Auto LED On ---
12 = Manual LED On ---
13 = All LEDs On ---
14 = Flash Voltage On ---
F27 Unsigned Integer: Auto Mode
Definition
FFFF
0 = Serial ---
1 = Hard-Wired ---
F28 Unsigned Integer: Overload Curve FFFF
1 = Curve # 1 ---
2 = Curve # 2 ---
3 = Curve # 3 ---
4 = Curve # 4 ---
5 = Curve # 5 ---
6 = Curve # 6 ---
7 = Curve # 7 ---
8 = Curve # 8 ---
9 = NEMA Class 10 ---
10 = NEMA Class 15 ---
11 = NEMA Class 20 ---
12 = NEMA Class 30 ---
F29 Unsigned Integer: ESD Indication FFFF
0 = OFF when healthy ---
1 = ON when healthy ---
F30 Unsigned Integer:
Normally Open / Normally Closed
FFFF
0 = N.O. ---
1 = N.C. ---
Table 6–13: DATA FORMATS (Sheet 8 of 15)
CODE DESCRIPTION BITMASK
