GE MOTOR MANAGER 2 User Manual

GE Power Management
MM2 Motor Manager 2 6-45
6 COMMUNICATIONS 6.6 DATA FORMATS
6
F31 Parity Type FFFF
0 = NONE ---
1 = EVEN ---
2 = ODD ---
F32 Contactor Sequence FFFF
0 = 1S-2S ---
1 = 2S-1S ---
F33 Manufacture Month/Day FFFF
Month: 1 = January, 2 = February...
12 = December
---
Day: 1 to 31 in steps of 1 ---
F34 Manufacture Year: Unsigned Integer FFFF
Year: 1995, 1996 ---
F35 Unsigned Integer: CT Connection Type FFFF
0 = 3 CTs ---
1 = 2 CTs (A and C) ---
F36 Simulated Switch State FFFF
0 = OPEN ---
1 = CLOSED ---
F37 Unsigned Integer: On / Off FFFF
0 = Off ---
1 = On ---
F100 Switch Input Status: FFFF
Interlock Input 1 0001
Interlock Input 2 0002
Interlock Input 3 0004
Interlock Input 4 0008
Interlock Input 5 0010
Interlock Input 6 0020
Interlock Input 7 0040
Interlock Input 8 0080
Interlock Input 9 0100
Interlock Input 10 0200
Stop 0400
Start A 0800
Start B 1000
Local Isolator N/O 2000
Contactor A N/O 4000
Contactor B N/O 8000
Table 6–13: DATA FORMATS (Sheet 9 of 15)
CODE DESCRIPTION BITMASK
F101 LED Status Flags 1 FFFF
Running 0001
Stopped 0002
Tripped 0004
Alarm 0008
Fault 0010
Test 1 0020
Test 2 0040
Not Used 0080
Not Used 0100
Not Used 0200
Not Used 0400
Not Used 0800
Not Used 1000
Not Used 2000
Not Used 4000
Not Used 8000
F102 LED Status Flags 2 FFFF
Contactor A Relay 0001
Contactor B Relay 0002
AUX 1 Relay 0004
AUX 2 Relay 0008
Auto 0010
Manual 0020
Beeper 0040
VFD test mode 0080
Not Used 0100
Not Used 0200
Not Used 0400
Not Used 0800
Not Used 1000
Not Used 2000
Not Used 4000
Not Used 8000
Table 6–13: DATA FORMATS (Sheet 10 of 15)
CODE DESCRIPTION BITMASK
