GE P645

Feature IEC 61850 ANSI
Trip circuit and coil supervision
Control inputs PloGGIO1
Power-up diagnostics and continuous self-monitoring
Dual rated 1A and 5A CT inputs
Alternative setting groups (4)
Graphical programmable scheme logic (PSL)
4.3 MEASUREMENT FUNCTIONS
Measurement Function IEC 61850 ANSI
Measurement of all instantaneous & integrated values
(Exact range of measur
ements depend on the device model)
MET
Disturbance recorder for waveform capture – specified in samples per cycle RDRE DFR
Fault Records
Maintenance Records
Event Records / Event logging Event records
Time Stamping of Opto-inputs Yes Yes
4.4 COMMUNICATION FUNCTIONS
The device offers the following communication functions:
Feature ANSI
NERC compliant cyber-security
Front RS232 serial communication port for configuration 16S
Rear serial RS485 communication port for SCADA control 16S
2nd Additional rear serial communication ports for SCADA control and
telepr
otection (fibre and copper) (optional)
16S
Ethernet communication (optional) 16E
Redundant Ethernet communication (optional) 16E
Courier protocol 16S
IEC 61850 protocol (optional) 16E
IEC 60870-5-103 protocol (optional) 16S
Modbus protocol (optional) 16S
DNP3.0 protocol over serial link (optional) 16S
DNP3.0 protocol over Ethernet (optional) 16E
IRIG-B time synchronisation (optional) CLK
