GE P645

CLIO
Current loop input DT operate time
20 Hz to 70 Hz: +/- 2% setting or 150 ms, whichever is greater
5 Hz to 20 Hz: +/- 2% setting or 200 ms, whichev
er is greater
Current loop input instantaneous operate time
20 Hz to 70 Hz: < 200 ms, whichever is greater
5 Hz to 20 Hz: < 300 ms, whichev
er is greater
Current loop output conversion interval 50 mS
Current loop output latency
< 1.07 s (1 s refresh rate)
< 70 ms (0.5 cy
cle refresh rate)
Current loop output accuracy +/- 5% of full scale
Repeatability < 5%
Current loop input load resistance
< 4 kohms (0-1 mA)
< 300 ohms (0-10 mA / 0-20mA / 4-20mA)
Isolation between input channels and case/earth/other
cir
cuits
2 kV RMS for 1 minute
Current loop output compliance voltage
10 V (0-1 mA / 0-10 mA)
8.8V (0-20 mA / 4-20 mA)
Current loop output open circuit voltage < 15V
P64x Chapter 21 - Technical Specifications
P64x-TM-EN-1.3 469
