GE P645

Terminal Number Current Loop Connection
Terminal 1 CLO1 - 20 mA input
Terminal 2 CLO1 - 1 mA input
Terminal 3 CLO1 - common input
Terminal 4 Not used
Terminal 5 CLO2 - 20 mA input
Terminal 6 CLO2 - 1 mA input
Terminal 7 CLO2 - common input
Terminal 8 Not used
Terminal 9 CLO3 - 20 mA input
Terminal 10 CLO3 - 1 mA input
Terminal 11 CLO3 - common input
Terminal 12 Not used
Terminal 13 CLO4 - 20 mA input
Terminal 14 CLO4 - 1 mA input
Terminal 15 CLO4 - common input
Terminal 16 CLI1 - 20 mA input
Terminal 17 CLI1 - 1 mA input
Terminal 18 CLI1 - common input
Terminal 19 Not used
Terminal 20 CLI2 - 20 mA input
Terminal 21 CLI2 - 1 mA input
Terminal 22 CLI2 - common input
Terminal 23 Not used
Terminal 24 CLI3 - 20 mA input
Terminal 25 CLI3 - 1 mA input
Terminal 26 CLI3 - common input
Terminal 27 Not used
Terminal 28 CLI4 - 20 mA input
Terminal 29 CLI4 - 1 mA input
Terminal 30 CLI4 - common input
