GE MEDICAL SYSTEMS PRECISION RXI SYSTEM PRE-INSTALLATION
D
IRECTION 5123449-100, REVISION 12
_____________________________________________________________________________________________
June 2009 Page 23 / 111
5. System Physical Characteristics
Refer to this section for the dimensional drawings of the components of the Precision RXi R&F System.
Note: Drawings are not to scale. Dimensions are called out on each drawing.
5.1. Dimension Overview
Component Width Height Depth Weight
Mounting
Comments
Table Assembly 2100mm 2340mm 2022mm 998kg Mount on floor
Table Cabinet 600mm 1960mm 340mm 170kg Bracket to wall
Generator Cabinet 459mm 1237mm 408mm 107kg Mount on floor
Integrated Console 900mm 1200mm 680mm
100kg
(without
components
mounted)
Mount on floor
19” LCD Monitor 418mm 424mm 226mm 9.7 kg
On desk stand or
mounted to
supporting
component
Positioner Console 650mm 150mm 500mm 25kg
Desktop or on
Integrated
Console
Digital PC 200mm 420mm 460mm 30kg
Floor standing or
on Integrated
Console
Generator Touch
Screen
365mm 326mm 85mm 4.5 kg
On desk stand or
on Integrated
Console
Single Monitor
Suspension
418mm
1946mm
(Max value)
1869mm 23 kg
Does not include
weight of
monitor
Double Monitor
Suspension
836mm
2016mm
(Max value)
1940mm 24 kg
Does not include
weight of
monitor
Single Monitor Cart 627 ÷ 709 mm 1338 mm 651 ÷ 691 mm 15,5kg
Does not include
monitor weight /
dimensions
Overhead Tube
Suspension
800mm 1275mm 600mm 140kg
Bridge (Tube or
Monitor)
3000mm 113mm 670mm 85 kg
Stationary Rails 1730mm 80mm 4400mm 90 kg
Non-tilting
Wallstand
620mm 2230mm 460mm 170 kg
Mount on floor
Tilting Wallstand 620mm 2230mm
990mm max
(tilted
horizontal)
200 kg Mount on floor
IMPORTANT
For details, please make reference to PORTEGRA2 Installation Manual PTZ15002E by
MAVIG
