GE MEDICAL SYSTEMS PRECISION RXI SYSTEM PRE-INSTALLATION
D
IRECTION 5123449-100, REVISION 12
_____________________________________________________________________________________________
June 2009 Page 85 / 111
10. System Cable Information
The following table contains all interconnect cables for the Precision RXi system.
rf: cable reference number in the connection diagrams
code: cable part number
cable description: cable description
m: usable cable length in meters
ft: usable cable length in feet
Source: the cable source connection
Destination: the cable destination connection
Mm: cable diameter in millimeters (not including connector)
Inch: cable diameter in inches (not including connector)
All the cables are UL with exercise temperature equal or superior to 80°C and nominal tension not inferior to 30V
for the Video cables and not inferior to 300V for all the others cables.
Cable length summary
To/From Usable Length
Pos Cab to In Room Monitor (power and video for analog,
power only for digital)
15.5m (51 ft)
Console to In Room Monitor (video for digital) 18m (59 ft)
Gen Cab to Console 14.5 m (47.5 ft)
Pos Cab to Console 14.5 m (47.5 ft)
Table to Console (digital only) 22 m (72 ft)
Gen Cab to Power 10m (32.8 ft)
Pos Cab to Power 10m (32.8 ft)
Gen Cab to Pos Cab 4 m (13.1 ft)
Gen Cab to OTS Susp (3m bridge) 14.5 m (47.5 ft)
Pos Cab to OTS Susp (3m bridge) 17.5 m (57.4 ft)
OTS Susp to Power 20m (65.6 ft)
Table to Gen Cab 5m (16.4 ft)
Table to Pos Cab 7m (23 ft)
Wall Bucky to Pos Cab 17.5 m (57.4 ft)
Wall Bucky to Generator 17.5 m (57.4 ft)
Make reference to service manual direction “5142538-100 Precision RXi Drawings” (MIS chart and MIS Maps).
The meaningful MIS Chart pages are attached to this manual.
