Cables colour codes
COMPONENT COLOUR
Generator cabinet Red
Positioner cabinet Yellow
Table Black
Integrated User Interface (console) Green
Wall Stand n.a
Overhead Tube Suspension (OTS) Blue
Monitor Suspension/cart Green
Modem Green
Network/Ethernet Green
Power mains board - generator Red
PDU – Positioner/Digital system Yellow
Injector Black
