GE MEDICAL SYSTEMS PRECISION RXI SYSTEM PRE-INSTALLATION
D
IRECTION 5123449-100, REVISION 12
_____________________________________________________________________________________________
June 2009 Page 21 / 111
4.2.2. Room Height Requirements
For a table with no longitudinal drive, the minimum room height is 240 cm (95”). For a table with longitudinal
drive, the minimum room height is 260 cm (103”). In both cases, the recommended room height is 300 cm (118”).
By default all tables have the longitudinal drive. In case of longitudinal drive forbidden, the height can be reduced to
240 cm.
However, for a system with OTS and wallstand, full range of wallstand use is achieved with a ceiling height of 290
cm. A higher height will limit the lower end of the useful travel range of the wallstand.
For all OTS dimensions and travels make reference to par. 5.2.10, page 50.
Minimum
ceiling
height
[cm]
Parameter
value
Precision RXi
Elevable positioner
-90 / +90
Precision RXi
NON Elevable positione
-30 / +90
From 0
to 239
???
WARNING!
The positioner movement is protected by
the hardware safety photocell only!
WARNING!
The Positioner movement is protected by
the hardware safety photocell only!
From 240
to 249
240
Table movements limited by software.
Table in horizontal position: the FD
2
has a
limited SID
3
(it never reaches 150 cm).
Table in vertical position: the tabletop has
no longitudinal drive.
Table movements limited by software.
Table in horizontal position: the FD has a
SID limited to 115 cm.
Table in vertical position: the tabletop has
no longitudinal drive.
From 250
to 259
250
Table movements limited by software.
Table in horizontal position: the FD has a
limited SID (it never reaches 150 cm).
Table in vertical position: the tabletop has
limited longitudinal drive.
Table movements limited by software.
Table in horizontal position: the FD has a
SID limited to 135 cm.
Table in vertical position: the tabletop has
limited longitudinal drive.
From 260
to 269
260
Table movements limited by software.
Table in horizontal position: the FD could
have a limited SID (no maximum SID and
maximum table elevation in the same
moment).
Table in vertical position: the tabletop has
limited longitudinal drive.
Table movements limited by software.
Table in horizontal position: the FD can
reach the maximum SID;
Table in vertical position: the tabletop has
limited longitudinal drive.
From 270
to 279
270
Table movements limited by software.
Table in horizontal position: the FD could
have a limited SID (no maximum SID and
maximum table elevation in the same
moment).
Table in vertical position: the tabletop has
limited longitudinal drive.
Table movements limited by software.
Table in horizontal position: the FD can
reach the maximum SID;
Table in vertical position: the tabletop has
limited longitudinal drive.
From 280
to 289
280
Table movements limited by software.
Table in horizontal position: the FD can
reach the maximum SID;
Table in vertical position: the tabletop has
limited longitudinal drive.
Table movements limited by software.
Table in horizontal position: the FD can
reach the maximum SID;
Table in vertical position: the tabletop has
limited longitudinal drive.
From 290
to 299
290
Table movements limited by software.
Table in horizontal position: the FD can
reach the maximum SID;
Table in vertical position: the tabletop has
its maximum longitudinal drive.
Table movements limited by software.
Table in horizontal position: the FD can
reach the maximum SID;
Table in vertical position: the tabletop has
its maximum longitudinal drive.
From 300
to ∞
300
Table without limited movements.
Table in horizontal position: the FD can
reach the maximum SID;
Table in vertical position: the tabletop has
its maximum longitudinal drive.
Table without limited movements.
Table in horizontal position: the FD can
reach the maximum SID;
Table in vertical position: the tabletop has
its maximum longitudinal drive.
2
FD = Focal Distance
3
SID = Source to Image Distance
