8.4. Electrical Requirements
8.4.1. Generator Electrical Requirements
Note: Shunt trip circuit breaker required.
The main circuit breaker supplied by the customer must be sized in accordance with local regulations and have
remote (shunt) trip.
8.4.1.1. System Power Specifications
VOLTAGE AND FREQUENCY REQUIREMENTS – US Systems
Precision RXi
COMPONENT
VOLTAGE FREQUENCY POWER
FACTOR
INPUT
IMPEDANCE
% REG
NOM MIN MAX NOM. MIN MAX
Generator 480
VAC, 3
phase
-10% +10% 60 Hz N/A N/A N/A 0.19 Ohm
(65KW)
0.15 Ohm
(80KW)
x % 2A
Positioner 230
VAC,
single
phase
-10% +10% 50/60 Hz N/A N/A N/A N/A N/A
Digital
Transformer
230
VAC,
single
phase
-10% +10% 50/60 Hz 49.5 Hz 60.5 Hz N/A N/A N/A
OTS 230VA
C,
single
phase
-10% +10% 50/60 Hz N/A N/A N/A N/A N/A
VOLTAGE AND FREQUENCY REQUIREMENTS – European Systems
Precision RXi
COMPONENT
VOLTAGE FREQUENCY POWER
FACTOR
INPUT
IMPEDANCE
% REG
NOM MIN MAX NOM. MIN MAX
Generator 400 VAC,
3- phase
-10% +10% 50 Hz N/A N/A N/A 0.13 Ohm
(65KW)
0.11 Ohm
(80KW)
Positioner 230 VAC,
single
phase
-10% +10% 50 Hz N/A N/A N/A N/A N/A
Digital
Transformer
230 VAC,
single
phase
-10% +10% 50 Hz 49.5 Hz 50.5Hz N/A N/A N/A
OTS 230VAC,
single
phase
-10% +10% 50/60 Hz N/A N/A N/A N/A N/A
