GE MEDICAL SYSTEMS PRECISION RXI SYSTEM PRE-INSTALLATION
D
IRECTION 5123449-100, REVISION 12
_____________________________________________________________________________________________
June 2009 Page 77 / 111
Box #1
Dimensions: 460x95x55 cm
181x37x21 inch
Item # Description
1 Case no. 1 cover
2 Packing list
3
Hose from the carriage to the rack l=6900
Hose from the x-ray tube to the carriage l=3100
4 Carriage cover (2 halves)
5 X-ray tube cover
6 Cover and cables box
7 Cable rail
8 Transversal bridge
9 Rail screws
10 Longitudinal Rails
11 Case n.1
Box #2
Dimensions: 100x75x140 cm
39x29x55 inch
Pos. Description
12 Case no. 2 cover
13 Manuals and documents
14 Case no. 2
15 Case no. 2 packing list
16 Stand on the pallet
17 Accessories box
18 Collimator (option)
19 case no. 2 lateral wall
9.1.2. Table
Box L x W x H Gross weight Contents:
#1 (elevating table)
1180x1280x2240 mm
47x51x88 inch
kg 770 ± 10%
Table cabinet, tilting group, control console,
covers
#1 (non-elevating table)
1180x1280x2240 mm
47x51x88 inch
kg 555 ± 10%
Table cabinet, tilting group, control console,
covers
#2
2340x1000x1900 mm
98x39x75 inch
kg 750 ± 5% Table on dolly
#3 (non-elevating table)
1060x1060x170 mm
42x42x67x7 inch
kg. 136 ± 5kg Base plate
#3 (elevating table with bolt
down base plate)
1090x1305x230 mm
43x51x9 inch
kg. 137 ± 5kg Base plate
Table cabinet, tilting group, control console and covers are expressed with their approximate gross weights. As
matter of fact, equipments gross weight depending also from the optional accessories inside the packing box.
Warning! In order to find out equipments effective weights make reference to the shipment packing list.
