GE MEDICAL SYSTEMS PRECISION RXI SYSTEM PRE-INSTALLATION
D
IRECTION 5123449-100, REVISION 12
_____________________________________________________________________________________________
Page 34 / 111 June 2009
5.2.1.2.3. -90/+90 Elevating Table cont.
Fixation by means of small blocks. Fixation plate for elevating table (weight: 100 kg).
Concrete floor, min. height: 200mm (concrete as per the Table “IN 1045 BN350”).
Small blocks of the LIEBIG M10 S15/70 type having a length of 145mm.
• Make 4 holes in the floor having a 15mm diameter x 145mm.
• By means of the special shims supplied, you shall level the plate with a flatness of max 0.7mm/m, (Fig.
2 page 35).
• Check the proper flatness by means of the special ruler supplie.
• Tighten the screws by means of a 50 N/m driving torque.
X-Rays beam middle reference line
