GE MEDICAL SYSTEMS PRECISION RXI SYSTEM PRE-INSTALLATION
D
IRECTION 5123449-100, REVISION 12
_____________________________________________________________________________________________
June 2009 Page 39 / 111
M10
455 15 30
300 406
85
REAR
36
Generator Anchoring Locations.
Note: The flanges indicated by dotted lines show optional positioning of the flanges at those corners
Note: All dimensions in mm
High voltage cables,
thermal switch, anode.
Power supply input
cable (3 phase).
TDI board; GIM connection;
A
EC board; DAP board;
Touch screen; RS232 remote
diagnostic
9
107
117
18.5
3.5
57
6 29
6
16 32.5
4
8
Room interface board;
1.5
4.5
32.5
